E2275SWJ
21.5 inch LED Monitor
GREEN
| Screen Size | 21.5"W |
| Viewable Image Size | 54.69cm |
| Pixel Pitch | 0.248 (H)×0.248 (V)mm |
| Display Area | 476.6 (H)×268.1 (V)mm |
| Brightness | 250 cd/m² |
| Contrast Ratio (typical) | 20000000:1 (DCR) |
| Response Time (typical) | 5ms |
| Viewing Angle | 170/160 (CR≥10) |
| Scan Frequency | H: 30K~83KHz V: 55~75Hz |
| Pixel Frequency | 148.5MHz |
| Recommended Resolution | 1920×1080@60Hz |
| Display Colours | 16.7M |
| HDCP Compatible | Yes |
| Input Signal | Analog RGB and DVI-D |
| Input Connector | 15-pin D-Sub and 24-pin DVI |
| Power Supply | 12VDC,3A |
| Power Consumption | Power On: <18W（Typical), Standby: <0.5W |
| Plug & Play | DDC 2B/CI or VESA DDC2B™ |
| User Control | Auto/Source/Exit; Clear Vision/<; 4:3wide/>;Menu, Power |
| OSD Languages | 16 Languages |
| Speakers | No |
| Safety & Regulations | CCC,CEL-1,China Rohs,FCC,CE/CB,cTUVus,TUV-S,TUV-Bauart,Windows 7,ISO9241-307,EPA,C-Tick N26268,CKT,EU RoHS Doc,KCC,BSMI |
| Wall-Mount | NA |
| Cabinet Colour | Black |
| Mechanical Function | Tilt: -5°~20° |
| W×H×D (w/base)mm | 512.3×385.3×196 mm |
| W×H×D (package)mm | 567×112×505 mm |
| Weight (Net /Gross) | 3.25Kg/4.9Kg |
