HAF 922 (RC-922M)      |
Introduction
Following the success of the full tower HAF 932, Cooler Master extends the line to a mid tower with the HAF 922. It has a rugged strong appearance and outstanding protection designs that characterize a beast yet to be tamed. Without a doubt this mid tower has it all! It accommodates all sorts of high-end hardware from its spacious interior, and supports up to three 200 mm fans for maximum airflow at minimum noise. This mid tower chassis represents a disorderly collision of machine and beast.
Features
- Extreme airflow, uncompromising cooling performance, ruggedly strong with outstanding protection
- Accommodates demanding high-end components including full length graphics cards
- LED ON/OFF switch for front 200 x 30 mm fan
- Patented button design for easy maintenance of 5.25" drive devices
- PSU bottom fan can be setup facing up or down to increase airflow through out the case
- Tool free installation
- Includes cable management and CPU retaining hole for easy customizability
- Spacious interior accommodates with the radiator
- 7+1 PCI expansion slots for increased expandability
Specifications
| Available Color | Black |
| Dimension (W / H / D) | Main: 253 x 502 x 563 mm / 10.0 x 19.7 x 22.2 inches Box: 285 x 550 x 605 mm / 11.2 x 21.7 x 23.8 inches |
| Weight | Net Weight: 8.7 / 10.9 kg Gross Weight: 19.2 / 24.0 lbs |
| Material | Steel + Plastic and Mesh Bezel |
| Motherboards | ATX / Micro-ATX |
| 5.25" Drive Bay | 5 Exposed (one could convert to 3.5" drive bay) |
| 3.5" Drive Bay | 5 Hidden 1 Exposed (converted from one 5.25" drive bay) |
| I/O Panel | USB 2.0 x 2, MIC x 1, Audio x 1 (supports HD / AC97 Audio), eSATA x 1 |
| Cooling System | Front: 200 mm fan x 1 Red LED on / off fan x 1 / 700 RPM / 19 dBA (can be swap for 120 / 140 mm fan x 1) Top: 200 mm fan x 1 / 700 RPM / 19 dBA (can be swap to 120 mm fan x 2 ) Rear: 120 mm fan x 1 / 1200 RPM / 17 dBA Bottom: 120 / 140 mm fan x 1 (optional) Side: 200 mm fan x 1 (optional) (can be swap for 120 mm fan x 2) |
| Expansion Slots | 7 + 1 |
| Power Supply | ATX PS2 / EPS 12V (optional) |
| Optional Component | Transparent Acrylic Side Panel |
